MIMAKI UJV300DTF-75 UV-DTF Printer

UV-DTF : Create High Value-Add Printing Business

---

"UJV300DTF-75" is a Mimaki's first UV-DTF (UV curable – Direct To Film) printer.

UV-DTF is a decoration method in which a design printed on a special film is transferred to the target material. It can easily decorate the surface of materials with uneven or curved surfaces, which has been difficult with conventional UV printing.

UV-DTF's exclusive film consists of two parts: a glued film and a transfer sheet.

UV-DTF eliminates the need for weeding (removal of margins) manually and allows confirmation of printed content before transfer, which significantly improves production efficiency and waste rates.

---

---

Mimaki Quality: High image quality and stability

---

The "UJV300DTF-75" is a UV-DTF printer that can be used with confidence, inheriting the high image quality and stable functions of our "UCJV300 series" UV inkjet printers, which continue to gain a high reputation in the market.

• Less graininess and beautiful gradation. Accurate printing of small characters and fine lines
• Support functions to minimize trouble. Automatic nozzle check [NCU] and nozzle recovery functions [NRS] reduce equipment downtime
• Ink circulation function [MCT] keeps white ink density constant and prevents nozzle clogging
• Media jam sensor prevents collision between the head and the film to prevent malfunctions due to operation errors

Specifications

UJV300DTF-75
Print head		On-demand piezo head
Print resolution		300dpi, 600dpi, 900dpi, 1200dpi
Ink	Type/Color	UV curable flexible ink ELS-170 (C, M, Y, K) UV curable hard ink ELH-100 (White, Clear)
	Capacity	1L bottle
Ink circulation system		Available only for white ink
Max. print width		640mm (25.2 in)
Media	Max. width	650 mm (25.6 in)
	Roll diameter	φ250 mm (9.8 in) or less
	Roll weight	45 kg (99.2 lb) or less
Interface		USB2.0 / Ethernet 1000 BASE-T
Certifications		VCCI class A / FCC class A / ETL IEC 62368-1 / CE Marking (EMC, Low voltage, Machinery directive and RoHS) / CB / REACH / Energy Star / RCM / KC
Power supply		Single-phase AC100-120 / 200-240V±10%, 50/60Hz±1Hz x 1
Power consumption		AC100V: 1.44kW or less / AC200V: 1.92kW or less
Operational environment		Temperature: 20-30 degC / 68-86 degF Humidity: 35-65% Rh (Non condensing)
Dimensions (W×D×H)		2,090 x 930 x 1,475 mm (82.3 x 36.6 x 58.1 in)
Weight		180 kg (396.8 lb)

---

Production Example of UJV300DTF-75

---

*Click to view larger image.

Helmet	Mug	Electric kettle	Flower pot
Wine glass	Skateboard	Electronic device	Trash can (Functional Indication)
